Kramer Electronics TBUS-6xl[B]

Table Mount Modular Multi–Connection Solution

• Rectangular
• Retractable Lid
• Modular Design

The TBUS−6xl is the enclosure of a new modular system with a tilt−up lid. A complete TBUS system requires the enclosure an inner frame a power socket inserts and a power cord.

NOTE: The TBUS enclosure power socket power cord & inserts are purchased separately.

• Inner Frame — 3 different T6F inner frame options are available.
• Power Sockets — 8 different TS single power socket options are available to accommodate the power requirements worldwide.
• Power Cord — 8 different C–AC single power cords (and 3 Y power cords) for each power socket.
• Optional Accessories — TBUS Brackets K–Able Box Cable Reels Step–In Modules and Controllers are available.
• Retractable Lid — Manually slides into unit.
• Connector Depth — Adjustable.
• Installation Requirement — Table cutout of 225mm x 123mm (8.87 x 4.85).
• Dimensions — Top plate: 24.3cm x 14.0cm (9.6 x 5.5) W D; Enclosure: 22.1cm x 10.2cm x 13.0cm (8.7 x 4.0 x 5.1) W D H.
• Weight — 1.35 kg (2.8 lbs) approx.; table clamps: 0.25 kg (0.6 lbs) approx.
